Ize Compose

Multilingual writing firmware for the Zerowriter Ink (Inkplate 5 V2). Started as a multi-language writing firmware and now supports 92 keyboard layouts across dozens of scripts.

Current release: v1.4.1

Code repository: github.com/ize-studio/ize-compose

Initial startup image

v1.3.0 adds Wi-Fi client document-server mode, splits browser support into SD-loadable files, and preserves the SD settings backup flow.

v1.4.0 adds the top-level Sync flow for GitHub private repository sync, then turns the Wi-Fi adapter off after sync. The Bluetooth feature that acted as an external keyboard in v1.3.0 was removed because of battery-use issues. See RELEASE_1.4.1.md for the current release notes and RELEASE_1.4.0.md for the original v1.4.0 release.

For browser usage details, see WEB_INTERFACE.md.

Hardware scope warning

This repository is currently released for Zerowriter Ink only. Even if another device has an ESP32 and an e-ink display with matching or similar specifications, this code and firmware should not be treated as a general Inkplate/ESP32 writing firmware yet.

In particular, the keyboard input path is written for the current Zerowriter Ink hardware configuration. If the keyboard, keyboard controller, wiring, or input method changes, the input-handling code must be reviewed and modified before use.

Supported Device

Features

Writing

Keyboard & Language

Files

Display

Settings and updates

SD Card Required Files

The firmware expects support files on the SD card under /ize_compose/.

SD card path Required Purpose
/ize_compose/initial.png Recommended Boot/sleep image
/ize_compose/ize_compose_1-4-1.html Required for browser UI Unified Documents, Settings, Update, and GitHub settings page
/ize_compose/hwalja/hwalja_hangul.bin Recommended for multi-language Hangul input Hangul syllable font
/ize_compose/hwalja/hwalja_jamo.bin Recommended for multi-language Hangul input Hangul jamo/composition font
/ize_compose/hwalja/hwalja_latin.bin Recommended Full Latin and Latin-extended font
/ize_compose/hwalja/hwalja_jp.bin Optional Japanese Hiragana/Katakana
/ize_compose/hwalja/hwalja_greek_cyrillic.bin Optional Greek and Cyrillic
/ize_compose/hwalja/hwalja_arabic.bin Optional Arabic-script layouts
/ize_compose/hwalja/hwalja_indic.bin Optional Indic-script layouts
/ize_compose/hwalja/hwalja_sea.bin Optional Thai, Khmer, Lao, Myanmar, Tibetan
/ize_compose/hwalja/hwalja_misc.bin Optional Ethiopic, Georgian, Armenian, and other scripts
/ize_compose/settings_backup.json Generated Settings backup written by the firmware. Keep it when preserving settings across reset/reinstall.
/ize_compose/upload/izefirmware.bin Temporary Staged firmware file used internally during SD OTA update

When using files directly from this repository, make sure the final SD card paths match the table above. Font files must end up inside /ize_compose/hwalja/.

initial.png must be a PNG file, should be prepared at 1280x720, and must stay under 500 KB. The firmware loads it into memory before display; files larger than 500 KB are skipped. The image is centered on the active display canvas and is not automatically scaled down, so oversized images are clipped from the center rather than resized.

The repository sdcard/ize_compose/ folder contains the unified browser page. Font binaries may be distributed separately or generated from the font tools; the device still expects them at the paths listed above.

Device Menu and Web Pages

The main device menu is intentionally small:

Sync, New, Save, Count, Sleep, Network

Use Sync for one-shot GitHub document sync. Use Network for Off, WiFi, or WebServer.

The device screen shows the WebServer password until the browser PIN is accepted. WebServer mode starts its automatic shutdown tracking only after PIN authentication. After that authenticated client session has existed and no clients remain connected for more than 2 seconds, WebServer mode shuts down automatically. Use Ctrl + Menu to exit manually.

Detailed browser workflow is documented in WEB_INTERFACE.md.

GitHub Sync Scope

Top-level Sync is intended to keep Ize Compose SD-card documents and one private GitHub repository folder aligned.

Do not put a repository-side index.html document manager in the private writing repository. Private GitHub HTML files cannot be opened as a live web page without downloading them first, so online file management is not part of this release.

Keyboard Layouts (92)

The firmware includes 92 keyboard layouts. The authoritative layout names and keymaps are defined in src/jado.h; this README keeps the count and points to the source instead of duplicating a long multilingual list.

Font Files

The firmware has a built-in Latin fallback font. The full Latin font and all non-Latin script fonts are loaded from SD card at boot when the font files are present.

In a release install package, these files should be arranged under:

Ize-compose/sdcard/ize_compose/hwalja/

Copy the contents of Ize-compose/sdcard/ to the root of the SD card. The device expects the font files in /ize_compose/hwalja/.

File Scripts covered
hwalja_hangul.bin Multi-language Hangul syllables
hwalja_jamo.bin Multi-language Hangul jamo/composition glyphs
hwalja_latin.bin Latin and Latin extended
hwalja_jp.bin Japanese (Hiragana, Katakana)
hwalja_greek_cyrillic.bin Greek, Cyrillic
hwalja_arabic.bin Arabic, Persian, Urdu, Pashto, Kurdish Arabic
hwalja_indic.bin Devanagari, Bengali, Gujarati, Kannada, Malayalam, Punjabi, Tamil, Telugu, Sinhala
hwalja_sea.bin Thai, Khmer, Lao, Myanmar, Tibetan
hwalja_misc.bin Ethiopic, Georgian, Armenian, and others

Without these files the device still works, but only the built-in Latin fallback font is available.

v1.1.1 Arabic font update

hwalja_arabic.bin was regenerated in v1.1.1 so Arabic presentation forms use the full 8-pixel cell width. This reduces unwanted left/right blank space and improves visual connection between glyphs that should join.

Build Environment

Platform / Board / Framework

Item Value
Platform espressif32
Board esp32dev + Inkplate 5 V2 build flags
Framework Arduino
CPU clock 240 MHz
Upload / monitor speed 921600 baud

board = esp32dev is used with manual build flags rather than a dedicated Inkplate board definition. This firmware will not work on a generic ESP32 dev board. The flags, PSRAM assumptions, display path, and keyboard input code are specific to the Zerowriter Ink / Inkplate 5 V2 hardware.

Libraries

Library Version Source
InkplateLibrary 11.0.0 lib/ (local, no separate install needed)
SdFat 2.3.1 PlatformIO registry
U8g2_for_Adafruit_GFX 1.8.0 PlatformIO registry
Adafruit GFX Library 1.12.6 PlatformIO registry
Adafruit BusIO 1.17.4 PlatformIO registry

Build flags

Flag Purpose
-DARDUINO_INKPLATE5V2 Board identification
-DINKPLATE_5V2 Enables correct code path inside InkplateLibrary
-DBOARD_HAS_PSRAM Declares PSRAM presence to ESP-IDF
-mfix-esp32-psram-cache-issue Workaround for ESP32 PSRAM cache bug (older silicon)
-DSCREEN_WIDTH=800 / -DSCREEN_HEIGHT=600 Display resolution constants
-Os Size optimization for OTA-safe firmware size
-DIZE_INKPLATE_MINIMAL_IMAGE=1 Keeps only the image loading path this firmware uses
-DIZE_ENABLE_DIRECT_GITHUB_SYNC=1 Builds the direct GitHub sync path
-DIZE_ENABLE_BLE_KEYBOARD=0 Keeps removed Bluetooth keyboard code out of the build
-D CORE_DEBUG_LEVEL=0 Suppresses all serial debug output

Flash / partition settings

Item Value
Partition table min_spiffs.csv
Flash speed 80 MHz
Flash mode QIO (quad I/O)

The clean v1.1.1 package includes min_spiffs.csv at the project root so the build does not depend on a hidden PlatformIO package path.

Installation

Requirements

Download or open the Ize-compose/ package.

  1. Upload Ize-compose/firmware/izefirmware.bin as the firmware image.
  2. Copy the contents of Ize-compose/sdcard/ to the SD card root.
  3. Confirm that the SD card contains /ize_compose/initial.png, /ize_compose/ize_compose_1-4-1.html, and /ize_compose/hwalja/*.bin.

Build and flash from source

git clone <this repo>
cd <repo>
pio run --target upload

SD card setup

  1. Format SD card as FAT32.
  2. Create /ize_compose/ and /ize_compose/hwalja/ on the SD card if they are not already present.
  3. Copy initial.png to /ize_compose/. Use a 1280x720 PNG under 500 KB.
  4. Copy ize_compose_1-4-1.html to /ize_compose/.
  5. Copy hwalja_*.bin font files into /ize_compose/hwalja/.
  6. Keep settings_backup.json if it exists and you want to preserve settings across reset/reinstall.

Firmware OTA update (WiFi)

If the device is already running v1.3.x, update from the WebServer or WiFi browser page. If the installed firmware does not provide that browser update page, disconnect the keyboard cable and connect the device by USB for a wired firmware upload.

  1. Open Menu -> Network -> WebServer or Menu -> Network -> WiFi.
  2. Enter the 4-digit PIN on the device.
  3. Connect to the device access point from a PC or phone.
  4. Open http://192.168.4.1/ in a browser.
  5. Select the firmware file. The upload page sends it as izefirmware.bin.
  6. Wait for the device update/reboot flow to finish.

For document transfer, settings recovery, and update usage, see WEB_INTERFACE.md.

Keyboard Shortcuts

Shortcut Action
Ctrl+Space Toggle selected language / English mode
Ctrl+L Sleep (shows boot image)
Ctrl+F Text search
Ctrl+C Copy all text to clipboard
Ctrl+V Paste clipboard
Space (accent cycling) Cycle diacritic variants for last character

Repository Structure

Ize-compose/
  firmware/
    izefirmware.bin       - release firmware image
  sdcard/
    ize_compose/
      initial.png         - boot/sleep image
      ize_compose_1-4-1.html - unified browser page
      hwalja/
        hwalja_*.bin      - font files to copy to SD card
      settings_backup.json - generated settings backup, if present
  src/                    - clean PlatformIO firmware source
  lib/InkplateLibrary/    - local Inkplate driver required for build
  others/                 - font sources and helper tools, not compiled
  WEB_INTERFACE.md        - browser page usage guide
  INSTALL.md              - install/build notes
  RELEASE_1.4.1.md   - v1.4.1 release notes
  RELEASE_1.4.0.md   - v1.4.0 release notes
  RELEASE_1.1.2.md        - v1.1.2 release notes
  RELEASE_1.1.1.md        - v1.1.1 release notes

src/
  IZEcompose.ino        - main firmware
  jado.h                - keyboard layout definitions and keymaps (92 layouts)
  jeong_eum.h           - multi-language composition engine and script engine types
  insoe.h               - text rendering, font selection
  PsramAssets.h         - PSRAM asset loading helpers

lib/
  InkplateLibrary/      - Inkplate driver (local copy)

tools/
  make_fonts.py         - script used to build hwalja_*.bin from font sources
  u8g2/bdfconv.exe      - BDF font converter (used by make_fonts.py)

build/
  fontbuild*/           - intermediate font build artifacts
  noto_fonts/           - source Noto font TTFs used for font building

others/
  *.ttf                 - original/reference font files
  reference-headers/    - unused generated/reference headers, not compiled

platformio.ini          - PlatformIO build config

Current Limitations

Credits

I build strange little writing tools.
If you enjoyed this project, coffee support is welcome.

Ko-fi: https://ko-fi.com/dievesa

v1.4.1 unified browser note

/ize_compose/ize_compose_1-4-1.html replaces the previous separate property_update.html and document_server.html pages. WiFi mode and WebServer mode serve the same page with Documents and Settings & Update tabs.

WebServer mode uses the fixed SSID IZEcompose_FileServer, but the device now asks for a 10-digit numeric Wi-Fi password before starting the access point. The password is shown on the device until the browser PIN is accepted. Automatic shutdown starts only after PIN authentication; after an authenticated client session has existed, WebServer mode shuts down if no clients remain connected for more than 2 seconds.

Online firmware update is connected to firmware endpoints. Local SD upload remains the supported path for fonts and initial.png.

v1.4.1 online update assets

Online update checks the GitHub release firmware asset and the SD web-page asset. If the release includes a newer ize_compose_<version>.html, the device downloads that SD web page before starting firmware OTA. OTA begins only after every required download has completed.

The web page filename includes the firmware/web-page version, for example ize_compose_1-4-1.html, so the currently served page is not overwritten while the browser is open.

Source and releases: github.com/ize-studio/ize-compose
